Camera Image Sensor 1/2.7¨ Progressive Scan CMOS Min. Illumination Color: 0.01 Lux @(F1.2; AGC ON), 0.028 Lux @(F2.0; AGC ON) Shutter Speed 1/3 s to 1/100,000 s Slow Shutter Yes Auto-Iris No Day & Night IR Cut Filter Digital Noise Reduction 3D DNR Wide Dynamic Range DWDR 3-Axis Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° Lens Focal length 2.8/4/6 mm Aperture F2.0 Focus No FOV 2.8 mm, horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 136° 4 mm, horizontal field of view: 86°, vertical FOV: 46°, diagonal FOV: 102° 6 mm, horizontal field of view: 54.5°, vertical FOV: 31.3°, diagonal FOV: 62.3° Lens Mount M12 IR IR Range Up to 30 m Wavelength 850nm Compression Standard Video Compression Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG H.264 Type Baseline Profile/Main Profile/High Profile H.264+ Main stream supports H.265 Type Main Profile H.265+ Main stream supports Video Bit Rate 32 Kbps to 8Mbps Smart Feature-set Behavior Analysis Line crossing detection, intrusion detection Region of Interest Support 1 fixed region for main stream Image Max. Resolution 1920 × 1080 Main Stream 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) Sub Stream 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) Image Enhancement BLC/3D DNR Image Settings Rotate mode, saturation, brightness, contrast and sharpness are adjustable via client software and web browser Day/Night Switch Auto/Scheduled/Day/Night Network Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD error, HDD full Network Storage Support built-in microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour General Function One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark API ONVIF(PROFILE S,PROFILE G), ISAPI Simultaneous Live View Up to 6 channels User/Host Up to 32 users 3 levels: Administrator, Operator and User Client iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 Web Browser IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+ Interface Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port On-board Storage Built-in microSD/SDHC/SDXC slot, up to 128 GB Reset Button Yes General Operating Conditions -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) Power Supply 12 VDC ± 25% PoE: 802.3af, class 3 Power Consumption and Current 12 VDC, 0.3 A, max. 4 W PoE (802.3af, 36 to 57 V), 0.2 A to 0.1 A, max. 5.5 W Protection Level IP67 Material Front cover: plastic, back cover: metal Dimensions 69.7 mm × 67.9 mm × 171.4 mm (2.7¨ × 2.7¨ × 6.7¨) Weight 350g (0.8lb) |
