| Mechanical |
| Dimensions |
88 x 40 x 230 mm (3.47 x 1.58 x 9.06") |
| Weight |
400 g (14.11 oz) |
| Enclosure material |
Die-cast aluminum |
| Mounting |
Pole mounting (kit Included) |
| Wind loading |
342.5 N at 200 km/h (77 lbf at 125 mph) |
| Hardware |
| Networking interface |
(1) GbE RJ45 port |
| RF Connectors |
(2) RP-SMA (Waterproof) (1) GPS (Waterproof) |
| Power method |
Passive PoE (pairs 4, 5+; 7, 8 return) |
| Power supply |
24V, 1A Gigabit PoE adapter (Included) |
| Supported voltage range |
18—26V DC |
| Max. power consumption |
9.5W |
| LEDs |
(4) Signal strength: software_adjustable to correspond to custom RSSI levels GPS, LAN, power |
| RoHS compliance |
Yes |
| Shock and vibrations |
ETSI300-019-1.4 |
| Operating temperature |
-40 to 80° C (-40 to 176° F) |
| Operating humidity |
5 to 95% noncondensing |
| Certifications |
CE, FCC, IC |
| Software |
| Modes |
Access Point, station |
| Channel sizes PtP mode PtMP mode |
10/20/30/40/50/60/80 MHz 10/20/30/40 MHz |
| Services |
Web server, SNMP, SSH server, telnet , ping watchdog, DHCP, NAT, bridging, routing |
| Utilities |
airMagic, airView, antenna alignment tool, discovery utility, site survey, ping, traceroute, speed test |
| Distance adjustment |
Dynamic Ack and Ackless mode |
| Power adjustment |
Software adjustable UI or CLI |
| Security |
WPA2 AES only |
| QoS |
Supports packet level classification WMM and user customer level: High/Medium/Low |
| Statistical reporting |
Up time, packet errors, data rates, wireless distance, Ethernet link rate |
| Ubiquiti specific features |
30/50/60 MHz Channels, airMAX ac mode, traffic shaping with burst support, discovery protocol, frequency band offset, Ackless mode |
| Operating Frequency (MHz) |
| Worldwide |
5150–5875 MHz |
| USA U-NII-1: U-NII-2A: U-NII-2C: U-NII-3 |
5150–5250 MHz 5250–5350 MHz 5470–5725 MHz 5725–5850 MHz |
| Management Radio (MHz) |
| Worldwide |
2412–2472 MHz |
| USA |
2412–2462 MHz |
